LB7, LLY, LBZ, LMM, LML Cooling and Transmission

Why Does Your LB7, LLY, LBZ, LMM, LML Duramax Need Fuel Filter, Transmission Cooler, and Crankshaft Seal Service Parts?

Because the three systems covered here are exactly where an honest Duramax starts showing its age once the miles and the towing hours pile up. These are not upgrade parts chasing horsepower, they are the service hardware that stops leaks, restores prime, and keeps ATF and engine oil where they belong.

The Factory Fuel Filter Head Air-Leaks and Loses Prime

The stock fuel filter head on a 6.6L Duramax is a known weak point across the LB7, LLY, LBZ, LMM, and LML. The plastic housing warps and the hand primer wears out, so the head draws air into the fuel system and slowly bleeds off prime.
The first sign is a hard start after the truck sits, followed by a fuel system you have to re-prime by hand every few mornings.
Owners chasing this with a new factory head are buying the same failure again, which is why a fuel filter delete or bypass is the permanent fix when filtration moves to a FASS or AirDog lift pump.

The Allison Transmission Cooler Lines Fail at the Crimp

The factory Allison cooler lines on the 2006 to 2010 LLY, LBZ, and LMM crack right at the crimp where the rubber hose is pressed onto the metal line.
ATF weeps out, often mistaken for engine oil at first, and a fully blown line can dump enough fluid to trigger a shift inhibit and limp the truck.
Every Duramax-equipped GM through the LMM years shares this failure, so the upgraded transmission cooler repair line is a proactive fix, not just a repair after a puddle shows up.

The Two-Piece Rear Main Seal Weeps Oil Down the Block

The rear main seal on the Duramax is a two-piece design, and after years of heat cycling the lip hardens and the seal weeps oil down the back of the block and onto the bellhousing.
Pounded in crooked, or seated at the wrong depth, and a fresh seal leaks worse than the one it replaced.
The crankshaft seal driver kit exists so the new seal goes in square and true on the first try, covering the front and rear main seal across LB7 through LML.

What Can These Duramax Service Parts Solve?

Fuel Filter Delete and Bypass Kits Clean Up the Leaky Filter Head

The fuel filter delete kits use a CNC-machined 6061-T6 billet aluminum block-off plate, anodized barbed fittings, and high-pressure Viton O-rings to remove the air-leaking factory filter head and route fuel cleanly once your FASS or AirDog lift pump handles filtration.
This kills the air intrusion and prime loss at the source instead of chasing it with a replacement factory head.

The Upgraded Transmission Cooler Repair Line Eliminates the Failure-Prone Crimp

The transmission cooler repair line is built from high-pressure reinforced rubber hose with CNC-machined fittings and stainless steel crimp ferrules, sized as a direct replacement for the 2006 to 2010 LLY, LBZ, and LMM Allison lines.
It removes the crimp that cracks and leaks on the factory line and restores full, leak-free flow to the auxiliary cooler under tow.

The Crankshaft Seal Driver Kit Seats a Fresh Seal Square and True

The crankshaft seal driver kit uses a CNC-machined driver and centering shaft to seat the two-piece front and rear main crankshaft seal at the correct depth without distorting the lip.
It turns a fiddly, leak-prone job into a clean install that holds oil, covering every Duramax variant from the 2001 LB7 through the 2016 LML.

Shop Duramax Fuel Filter, Transmission Cooler & Crankshaft Seal Parts by GM Engine & Fitment Guide

• Fuel Filter Delete Kits (3 options) - Fits 6.6L Duramax LB7, LLY, LBZ, LMM, LML in Chevy Silverado & GMC Sierra 2500 HD, 3500 HD (2001-2016). CNC-machined 6061-T6 billet aluminum block-off plate, anodized barbed fittings, and high-pressure Viton O-rings that remove the air-leaking factory filter head and move filtration to your FASS or AirDog lift pump.
• Upgraded Transmission Cooler Repair Line - Fits 6.6L Duramax LLY, LBZ, LMM in Chevy Silverado & GMC Sierra 2500 HD, 3500 HD (2006-2010, Allison). High-pressure reinforced rubber hose with CNC-machined fittings and stainless steel crimp ferrules that replaces the failure-prone factory Allison cooler line crimp.
• Crankshaft Seal Driver Kit - Fits 6.6L Duramax LB7, LLY, LBZ, LMM, LML in Chevy Silverado & GMC Sierra 2500 HD, 3500 HD (2001-2016). CNC-machined driver and centering shaft that seats the two-piece front and rear main crankshaft seal at the correct depth without distorting the lip.

Why Choose EGR Performance?

The industry standard for high-performance diesel reliability.

Premium Quality & Rigorous Testing

Our EGR, DPF, and CCV delete kits are engineered from premium-grade materials and subjected to brutal quality control and field testing. Unlike generic alternatives, our products are built to withstand extreme heat and pressure, delivering unmatched durability and long-term stability when your rig needs it most.

20 Years of Proven Diesel Expertise

We aren't just selling parts. We live in this industry. With two decades of hands-on experience providing specialized modification solutions for heavy-duty truck owners, our upgrades have been extensively proven across every driving environment, from daily towing to high-performance tracks.

Industry-Leading Standards

We work hand-in-hand with top-tier industry partners and reputable organizations. Every product we design, test, and ship meets or exceeds strict industry standards, ensuring your Powerstroke, Cummins, or Duramax gets the exact precision it deserves.

Real Results, Proven Track Record

Thousands of diesel owners trust us to unlock their engine's true potential. Our massive library of positive customer feedback and successful build case studies proves one thing: our kits deliver real horsepower, lower EGTs, and flawless reliability in the real world.

What does a Duramax fuel filter delete actually do?

A fuel filter delete, also called a fuel filter bypass, removes the factory fuel filter head or filter bowl from the engine and routes fuel straight through once your filtration is handled upstream.
The factory filter head on the 6.6L Duramax is a known weak point that air-leaks and loses prime, so the delete cleans up the leaky housing and simplifies the fuel system.
Our kits use a CNC-machined 6061-T6 billet aluminum block-off plate, anodized barbed fittings, and high-pressure Viton O-rings for a clean, leak-free seal across LB7, LLY, LBZ, LMM, and LML.

Why delete the fuel filter head on a 6.6L Duramax?

Owners delete the filter head because it warps, the hand primer wears out, and the housing draws air into the fuel system that bleeds off prime overnight.
The classic symptom is a hard start after the truck sits, with a fuel system you have to hand-prime every few mornings.
When you add a FASS or AirDog lift pump that carries its own water separator and 2-micron filter, the factory head becomes redundant, so the delete removes the leak source instead of replacing it with the same failing part.

Can I run a fuel filter delete without a FASS or AirDog lift pump?

No, and this is the one detail to get right. The factory filter head is your only fuel filtration, so deleting it leaves you with zero filtration unless an aftermarket lift pump is doing that job upstream.
Run a fuel filter delete only after a FASS, AirDog, or similar system with its own filters is installed and plumbed in.
Without a lift pump, keep the factory filter head in place, because removing your only fuel filter will send debris straight to the injection system.

Why do LBZ and LMM transmission cooler lines leak?

The factory Allison transmission cooler lines on the 2006 to 2010 LLY, LBZ, and LMM crack right at the crimp where the rubber hose is pressed onto the metal line.
ATF weeps out from the cracked crimp, often mistaken for engine oil at first, and a fully blown line can dump enough fluid to trigger a shift inhibit and put the truck in limp.
Every Duramax-equipped GM through the LMM years shares this crimp failure, which is why the upgraded transmission cooler repair line is a proactive upgrade and not just a post-leak repair.

How do I replace the Allison transmission cooler lines on a 2006-2010 Duramax?

Our upgraded transmission cooler repair line is a direct replacement for the factory Allison lines on the 2006 to 2010 LLY, LBZ, and LMM, built from high-pressure reinforced rubber hose with CNC-machined fittings and stainless steel crimp ferrules.
The job is to relieve line pressure, catch the ATF, disconnect the factory lines at the cooler and the transmission, and install the new repair line using the supplied fittings.
Top off the Allison fluid to the hot-full line, run through the gears, and recheck for leaks under a tow load before you call it done.

What does the Duramax crankshaft seal driver kit fit?

The crankshaft seal driver kit fits every 6.6L Duramax from the 2001 LB7 through the 2016 LML, so it covers LB7, LLY, LBZ, LMM, and LML for both the front and rear main crankshaft seals.
The kit uses a CNC-machined driver and centering shaft sized to seat the two-piece seal at the correct depth on the Duramax crank.
If you are doing a rear main seal job on an LBZ or LMM, this is the tool that keeps the new seal from leaking worse than the old one.

Do I really need a special tool to install the Duramax rear main seal?

Yes, and it is the difference between a seal that holds and one that weeps from day one. The Duramax rear main is a two-piece seal that has to go in square and at the exact factory depth.
Driving it in with a socket or hammer distorts the lip and cock the seal, so it leaks almost immediately.
The crankshaft seal driver kit centers on the crank and drives the seal to the correct depth every time, which is why every Duramax forum recommends using the proper installer.

Is this the same as a Duramax oil bypass filter or remote oil filter kit?

No, and it is worth getting the terms straight before you order. This collection is fuel-side and transmission-side service hardware: a fuel filter delete for the leaky factory fuel filter head, an Allison transmission cooler repair line, and a crankshaft seal driver kit.
A Duramax oil bypass filter kit or remote oil filter kit is a completely different product that adds secondary engine oil filtration or relocates the oil filter, and we do not carry an oil bypass or remote oil filter kit in this collection.
If you specifically need an L5P bypass oil filter or a full bypass oil filtration system, confirm the exact product before ordering, because the fuel filter delete here will not serve that purpose.

What is the difference between the LBZ and LMM, and which parts fit each?

The LBZ is the 2006 to early 2007 Duramax at 360 hp and 650 lb-ft, and the LMM is the 2007.5 to 2010 version at 365 hp and 660 lb-ft, the first Duramax with a DPF but no DEF.
The upgraded transmission cooler repair line in this collection fits both, plus the 2006 LLY, covering the full 2006 to 2010 Allison range.
The fuel filter delete kits and the crankshaft seal driver kit reach even wider, fitting every Duramax from the 2001 LB7 through the 2016 LML, so a 2008 LMM and a 2014 LML both have a direct-fit option here.

Are these Duramax cooling and transmission parts street legal?

Yes for a stock truck. The fuel filter delete, the Allison transmission cooler repair line, and the crankshaft seal driver kit in this collection remove or bypass no emissions device, so they are 50-state street-legal fuel, transmission, and seal service parts for a daily-driven LBZ or LMM.
On tuned, deleted, or competition trucks the same parts may sit under a build intended for competition and closed-course off-road use only, and local emissions and equipment laws vary by jurisdiction, so confirm fitment and your local rules before ordering.
Every part in this collection includes free shipping, is backed by a 1-year warranty, and comes with our 45-day return policy.
