EGR Performance 6.0L Powerstroke EGR Delete Kit for Ford F250 F350 F450 F550 (2003-2007)

$48.99
Shipping calculated at checkout.
Style: EGR Delete
49 in stock, ready to ship
🛒 Bulk Discount: Save 6% on 2+ Items
🎁 Special Offer: Enjoy 10% Off on 3+ Items
📞 Large Orders (10+): Contact Us for Exclusive Deals
Details

Product Overview

The 6.0L Powerstroke EGR delete kit is the permanent fix for the worst failure on the 2003-2007 Ford F250, F350, F450, F550 Super Duty and Excursion 6.0L turbo diesel. It removes the factory EGR cooler and valve that rupture and dump coolant into the intake, ending hydrolock risk and lowering EGTs.

Every EGR delete kit for a 6.0 Powerstroke we ship is built from 304 stainless steel and CNC billet aluminum, pressure tested for a leak-free seal and a direct bolt-on fit that matches the factory mounting.

Y Pipe And Up Pipe

The 6.0L up pipe feeds the turbo, and the EGR delete seals its port with a block-off plug. A freer-flowing Y pipe cuts backpressure and spools the turbo quicker.

Oil Cooler

The 6.0 Power Stroke oil cooler runs hot once the EGR cooler leaks coolant. Upgrading it with the delete keeps oil temperatures down and protects the HPOP on long tows.

Intake Manifold Gasket

Fit fresh intake manifold gaskets while the intake is off for the delete. New gaskets seal the manifold to the heads and stop boost leaks on a high-mileage 6.0L.

Inlet Manifold Gasket

Inlet manifold gaskets sit at the intake-to-turbo passages and harden with heat. Replacing them during the delete keeps the fresh intake install clean and leak-free, so your 6.0L builds boost as it should.

Year and Model Fitment

Year Ford Model Engine
2003-2007 F-250 / F-350 / F-450 / F-550 Super Duty, Excursion 6.0L Powerstroke Diesel

Shop 2003-2007 6.0 Powerstroke EGR Delete Kit Now!

Shipping Details

Ontario CA / Springdale OH / Newark NJ

Package List
  • 1x Stainless Steel Coolant J-Tube Assembly with Billet Aluminum Block-Off Base
  • 1x Stainless Steel Exhaust Up-Pipe Plug
  • 1x Aluminum EGR Valve Block-Off Plate
  • 1x High-Temperature Silicone Hose / Coupler
  • 2x Stainless Steel Hose Clamps
Delivery Time

2-5 working days inland in the United States

Attention
Style

Product details

Core Advantages

Performance And Efficiency

  • Faster Turbo Spool: Eliminates backpressure and delivers cleaner intake air to accelerate turbo response on the 6.0L Powerstroke.
  • Lower EGTs: Keeps hot exhaust gas out of the intake, dropping operating temperatures and protecting the head gaskets.
  • Cleaner Combustion: Stops heavy soot buildup in the intake manifold for smoother acceleration and better fuel burn.

Durability And Reliability

  • 304 Stainless And Billet Aluminum: Corrosion-resistant materials built to handle extreme exhaust heat and high pressure.
  • Pressure Tested: Every cooler pipe and block-off plate is pressure tested for a 100 percent leak-free seal.

Maintenance Savings

  • Ends Hydrolock Risk: Removes the failure-prone factory EGR cooler that leaks coolant into the cylinders and wrecks the engine.
  • Fewer Repairs: No more EGR valve cleanings, cooler clogging, or blown head gaskets from thermal stress.

Ideal For

  • 2003-2007 Ford Super Duty Owners: F250, F350, F450, F550 and Excursion drivers with the 6.0L Powerstroke who want a permanent fix for factory EGR cooler failure.
  • Tuned And Towing Builds: Owners running a delete tune or hauling heavy loads that need lower EGTs and steady boost.
  • DIY Mechanics And Shops: Builders who want a direct bolt-on kit with stainless hardware, silicone couplers, and gaskets in the box.
  • Off-Road And Competition Trucks: Rigs that need maximum exhaust flow and cooler intake temps, off-road or race only.

Technical Specifications

  • Material: 304 stainless steel cooler pipe and CNC billet aluminum block off plates.
  • Compatibility: 2003-2007 Ford F250, F350, F450, F550 Super Duty and Excursion with 6.0L Powerstroke Diesel.
  • Testing: 100 percent pressure tested for zero leaks and heat resistance.
  • Design: Direct bolt-on OEM replacement that bypasses the factory EGR cooler and valve.
  • Finish: Metallic silver stainless with anodized billet plates.

Why Choose This EGR Delete Kit

  • Complete Hardware Kit: Stainless cooler pipe, up pipe block-off plug, silicone coupler, and heavy-duty clamps in every box.
  • Permanent Fix: Solves the most common factory defect on the 6.0L Powerstroke once and for all.
  • Precision Fitment: Direct bolt-on to OEM specs, no custom cutting or welding required.
  • Quality Guaranteed: Brand new, pressure-tested components built for heavy-duty use.

Complete Package Contents

  • 1x Stainless Steel Coolant J-Tube Assembly with Billet Aluminum Block-Off Base
  • 1x Stainless Steel Exhaust Up-Pipe Plug
  • 1x Aluminum EGR Valve Block-Off Plate
  • 1x High-Temperature Silicone Hose / Coupler
  • 2x Stainless Steel Hose Clamps

Fit Your Vehicle with 6.0L Powerstroke

This 6.0 Powerstroke EGR delete kit is built for the 2003-2007 Ford Super Duty and Excursion platform with the 6.0L Powerstroke V8 turbo diesel. The bolt-on design drops into the factory mounts with no fabrication, ready for your off-road build.

  • 2003-2007 Ford F-250 Super Duty (6.0L Powerstroke Diesel)
  • 2003-2007 Ford F-350 Super Duty (6.0L Powerstroke Diesel)
  • 2003-2007 Ford F-450 Super Duty (6.0L Powerstroke Diesel)
  • 2003-2007 Ford F-550 Super Duty (6.0L Powerstroke Diesel)
  • 2003-2007 Ford Excursion (6.0L Powerstroke Diesel)

Upgrade Your 6.0L Powerstroke Performance

The factory EGR cooler on the 6.0L Powerstroke is the weak link that sends coolant into the intake and stretches head bolts. Removing it with this delete kit cleans up the intake, drops EGTs, and lets the turbo breathe. For a complete bulletproof build, pair the delete with the supporting upgrades below, all tuned for the 2003-2007 6.0 Powerstroke platform.

Recommended 6.0L Powerstroke Performance Upgrades

  1. 6.0 Powerstroke Up Pipe: A freer-flowing up pipe and Y pipe that cuts backpressure and spools the turbo quicker after the EGR port is sealed.
  2. Best Upgrades For 6.0 Powerstroke: Our full guide to the parts that bulletproof a 2003-2007 6.0L, from deletes to tuning.
  3. 6.0 Powerstroke Tunes: The delete tune that disables EGR codes in the ECM so your truck runs clean with no check engine light.

Shop the full 6.0 Powerstroke range and get your off-road build sorted with fast shipping and real diesel support.

  1. Dispatch Time: Orders will be shipped within 24 hours after successful payment.
  2. Delivery Time: 2-5 business days after dispatch (delivery speed depends on proximity to warehouse location).
  3. Return Window:7 days for unsatisfactory items45 days for quality-related issues
  4. Refund Processing: Refunds will be processed back to your original payment method within 2-4 business days after receiving the automated refund confirmation email (subject to bank verification).

Frequently Asked Questions

Does this fit my 2005 Ford F-250 with the 6.0L Powerstroke?

A: Yes. This kit fits all 2003-2007 Ford F250, F-350, F450, and F-550 Super Duty trucks equipped with the 6.0L Powerstroke diesel engine.

Will this fit a 2004 Ford Excursion 6.0L Diesel?

A: Yes, this kit fits 2003-2007 Ford Excursions with the 6.0L Powerstroke engine, alongside the full Super Duty range.

Does this fit my 2006 Ram style F-350 6.0 Powerstroke?

A: Yes, the 2006 F350 6.0 Powerstroke EGR delete kit covers every 2003-2007 F-350 Super Duty with the 6.0L diesel.

How long does installation take?

A: Installation typically takes 4 to 6 hours for experienced mechanics. Professional installation is recommended because the up pipe sits behind the turbo and is hard to reach.

Do I need a tuner after installing this kit?

A: Yes. While the kit is bolt-on, an EGR delete tune or tuner is required to disable EGR codes in the ECM and prevent a check engine light.

Can I run a 6.0 Power Stroke EGR delete without a tuner?

A: Not recommended. Without a delete tune, the ECU still looks for the EGR system and will set fault codes, so a tuner is needed for a clean off-road run.

How does this kit protect my 6.0L Powerstroke engine?

A: Factory 6.0L EGR coolers rupture and send coolant into the intake and cylinders. This kit removes the cooler, stopping coolant leaks and preventing catastrophic engine damage.

Is this product legal for street use?

A: This kit is designed strictly for off-road and competition use only. Check your local emissions laws before installation, as it is not legal for public road use.

What materials are used in this delete kit?

A: The kit uses 304 stainless steel tubing for heat resistance and CNC billet aluminum block-off plates with high-temp silicone couplers, all pressure-tested.

Are installation instructions included in the box?

A: The kit contains all physical hardware shown in the product photos. Due to engine complexity, professional installation or a detailed service video is recommended.

Should I upgrade the 6.0 Power Stroke oil cooler too?

A: A leaking EGR cooler raises engine heat and oil temperature, so pairing the delete with a fresh oil cooler is a smart bulletproof move on a tuned or towing 6.0L.

Do I need new intake and inlet manifold gaskets?

A: It is best to fit fresh intake manifold gaskets and inlet manifold gaskets while the intake is off for the delete, sealing the manifold to the heads and stopping boost leaks.

Does this delete the EGR cooler or just the valve?

A: This is a full EGR cooler delete kit 6.0 powerstroke that removes both the cooler and the valve, sealing the up pipe port and the intake with block-off plates.

Which years are covered, including early 2004?

A: The kit is built for the 2003-2007 6.0L Powerstroke range. If you have an early 2004 truck, confirm your build date or VIN with us, since some early models use a different cooler style.

Installation Guide

The 6.0L Powerstroke EGR delete is a direct bolt on that replaces the factory EGR cooler and valve with a stainless cooler pipe and billet block off plates. Most builders finish in 4 to 6 hours, with the toughest part being access to the up pipe behind the turbo. We recommend a service manual or install video, and a tuner to disable EGR codes after the hardware is in.

What You Need

  • Basic hand tools, a socket set, and a torque wrench
  • New intake and inlet manifold gaskets (fit these while the intake is off)
  • A delete tune or EGR tuner to clear EGR related fault codes
  • Shop rags and a coolant catch pan (the factory cooler will drain coolant)

Install Steps

  1. Drain coolant and disconnect the battery. Remove the intake tubing to reach the EGR cooler and up pipe.
  2. Unbolt the factory EGR cooler and valve. Pull the cooler pipe and block off the up pipe EGR port with the supplied plug.
  3. Fit the stainless cooler pipe and billet block off plates with the new gaskets. Torque to spec and check the seal.
  4. Replace the intake and inlet manifold gaskets, reinstall the intake, and refill coolant with no air pockets.
  5. Flash the EGR delete tune. Start the truck, check for leaks, and confirm no EGR fault codes.

This kit is for off-road and competition use only. Removing emissions equipment is not legal for public road use under federal law, so confirm your local rules before you install.

📥 Download Complete Installation Guide:6.0L Powerstroke EGR Delete Kit Installation Guide (PDF)
