MiniMaxx V1 Updater
Details
The MiniMaxx V1 Updater from EGR Performance is the dedicated firmware update utility for your H&S Mini Maxx V1 diesel tuner. Use this software to flash the latest firmware, resolve device glitches, refresh tuning files and keep your MiniMaxx V1 running reliably for off-road diesel applications.
Important: Off-road use only. Vehicle owner is responsible for emissions and street compliance.
Pre-update Checklist
- A Windows PC
- Micro SD card from your MMV1, or any 8–16GB Micro SD card
- Micro SD to USB adapter (one included with the MMV1 unit)
- Stable internet connection
Update Process
- Remove the Micro SD card from your MMV1. Use the included USB adapter to connect the SD card to your Windows PC.
- Download and install our update agent.
- Launch the update program. The full process takes 10–30 minutes, depending on your internet speed and PC processor performance.
- When finished, safely eject the SD card from your computer and reinsert it into your MMV1.
- Power on the MMV1 using USB or the vehicle HDMI cable. Navigate the menu and select update firmware. The screen will dim during flashing; the unit will automatically reboot once done. Connect the MMV1 to your truck via HDMI cable and OBD adapter block.
- Connect a battery charger that delivers a constant minimum 10A output. Do NOT use smart chargers or booster packs that adjust amperage or time out. A proper fixed-output charger is required. Improper power supply can brick your PCM, and no support will be provided for damage caused by negligence.
- With the compatible battery charger connected, set ignition to ON. Open the MMV1 menu and select install download. Follow all on-screen prompts to finish installation.
- After installation completes, turn ignition OFF and disconnect the battery charger.
- The firmware update is finished. Perform a test drive to verify operation.
Key Features
- Official EGR Performance MiniMaxx V1 firmware update utility
- Refresh firmware and tune files for H&S Mini Maxx V1 tuner
- Fix common screen freeze and communication issues
- Works with Ford Powerstroke, Ram Cummins & GM Duramax supported by Mini Maxx V1
- Windows-only software; simple SD-card based flashing workflow
- Digital download only. No physical hardware shipped.
Compatibility
Only for H&S Mini Maxx V1 tuner. Not compatible with Mini Maxx V2 or other tuner models.
Shipping Details
Package List
Delivery Time
Attention
LEGAL DISCLAIMER
This product may NEVER be installed on a vehicle registered for highway or public street use. By installing this product onto your vehicle, you assume all risk and liability associated with its use. It is your responsibility to make sure your vehicle complies with all federal, state, and local emissions laws.
Federal and many state and local laws prohibit the removal, modification or rendering inoperative of any part of the design affecting emissions or safety on motor vehicles used on a public street or highway. Violation may result in a fine of up to $32,500 per vehicle (or possibly higher depending on changes in the law). All civil penalties and fines for removing your vehicle's emissions equipment are the sole responsibility of the end user.
No other applications besides off-road competition racing use are intended or implied. Depending on where you live, additional restrictions may apply. Check all applicable laws before installing or using.
Not available for sale or use in the state of California, Colorado and Arizona.
